MIL-UPS 1000 watts/VA

The MIL-UPS SeriesTM – Is a rugged 1000 Watts / VA full double conversion Rack mount
Uninterruptible Power Supply UPS in a 1 Unit rugged chassis that is less than 30 pounds.

Aenean convallis sapien nulla, et pretium dui luctus sed. Suspendisse lobortis est nibh, vel viverra libero lobortis sit amet. Vivamus pharetra pulvinar leo ut commodo. Maecenas dictum magna id risus fringilla, et ornare lorem consequat. Sed neque lorem, cursus in odio vitae, varius lobortis tortor. Maecenas sit amet orci leo. Vivamus nec sapien non nisi commodo aliquet. Nulla non dictum odio, vitae iaculis libero. Nulla eget pellentesque urna. Nullam scelerisque eros leo, quis sagittis dui suscipit sed. Vestibulum ante ipsum primis in faucibus orci luctus et ultrices posuere cubilia Curae; Pellentesque eleifend dolor quis feugiat porta. Morbi et nulla hendrerit, tincidunt libero in, molestie nibh.

Humidity | Altitude | Sand and Dust |
Shock and Vibration | Temperature

RE101 | RE102 | CE101 | CE102 | CE103

MIL-STD-1399-300B Type I

Ruggedized Military Tactical 1000 watts Uninterruptible Power Supply UPS Designed to meet the MIL STD 1275 and more

Ruggedized Tactical 1000 watts UPS is a Full Double Conversion 19” Rack Mount Tactical Uninterruptible Power Supply in a 1U (1.73” High) Ruggedized Chassis That is 26” in Length Weighing Less Than 30 Pounds.

The PowergridM technology is implemented with a Load Balancing Interconnect (LBI) design that allows up to four (4) of the PowergridM 1000 units to be interconnected to create a 1000, 2000, 3000 or 4000 Watts Uninterruptible Power Solution. The LBI interconnects the inverter and power circuits in each unit allowing them to work together to provide a fully meshed, load balanced and uninterruptible Powergrid for the attached systems. The PG1000 does not have a VDC input (Battery Expansion Capability) because it utilizes the available space and extended length to host larger Battery Packs to provide additional hold time for critical applications. 1U Ruggedized Rack mount Lightweight Uninterruptible Power Supply

EMI / EMC – PowergridM UPS system has been designed to comply with all the radiated emissions, susceptibility and conductive emissions requirements of the applicable sections of MIL STD 461F. The following is a list of methods used for controlling emissions: RE102 | CE102 | CS101 | CS114 | CS115 | CS116 | RS103 DESIGNED TO MEET
Environmental MIL-STD-810G: Humidity, Altitude, Sand and Dust, Shock and Vibration, Temperature.


• Ruggedized 1U 1000 Watts/VA weighing less than 30 Lbs.
• Stack and Interconnect Design 1000/2000/3000/4000 Watts.
• Dual Hot Swap Battery. 6 Lbs Each – 15+ Min Hold Time.
• Field Replaceable AC Input Power Module.
• Universal AC Input of 100-264 VAC & from 47 – 63, 400 Hz.
• VAC Output Voltage of 120V 60 Hz.
• Dual Computer Controlled Inverter N+1 Design.
• Over Voltage Capacity for Managed In-Rush and Start up.
• Over Voltage and Over Temperature Protection Circuits.
• Audible Power Loss Alarm with Enable/Disable Switch.
• Lightning Protection with Safety Ground Connection.

Special Features


1U 800 watts UPS – Rack mount Stackable to:
800 watts UPS | 1600 watts UPS | 2400 watts UPS | 3200 watts UPS

1U 1000 watts UPS – Rack mount Stackable to:
1000 watts UPS | 2000 watts UPS | 3000 watts UPS | 4000 watts UPS

1U 1500 VA UPS – Rack mount Stackable to:
1500 VA UPS | 3000 VA UPS | 4500 VA UPS | 6000 VA UPS

1U 1200 watts UPS – Rack mount Stackable to:
1200 watts UPS | 2400 watts UPS | 3600 watts UPS | 4800 watts UPS

2U 3000 VA UPS – Rack mount Stackable to:
3000 VA UPS | 6000 VA UPS | 9000 VA UPS

2U 2400 watts UPS – Rack mount Stackable to:
2400 watts UPS | 4800 watts UPS | 7200 watts UPS
