Industrial Battery Expansion Module – BackPlane 48 VDC Output – Industrial Battery Backup System UPS
The PG-BXM-BPM48 is a Rugged Rackmount 48V Battery Expansion Module Designed to Integrate With the 3U / 4U / 5U BackPlane System. The BXM Contains a Compliment of 8 Lithium Iron Phosphate Battery Packs Configured in the Cold PakTM Design. Industrial Battery Backup System UPS
The BXM is a 1U (1.73” High) rugged chassis that is 21.75” in length weighing 20 pounds. The BXM provides an additional 24+ minutes of battery support for the PowergridM UPS BackPlane Stacking System. The BXM can be plugged directly into the BPM in any available slot in support of a 1500 Watts BackPlane UPS stack.
• Plugs into any available slot in the BPM BackPlane.
• Hosts 1 removable Cold Pack Battery tray each containing 8 PowergridM battery modules.
• LED Operational Status Indicators for each battery tray.
• Same physical 1U size chassis package as the UPS.
• Each BXM provides a minimum of 24+ min of hold time.
1U 800 watts UPS – Rackmount Stackable to:
800 watts UPS | 1600 watts UPS | 2400 watts UPS | 3200 watts UPS
1U 1000 watts UPS – Rackmount Stackable to:
1000 watts UPS | 2000 watts UPS | 3000 watts UPS | 4000 watts UPS
1U 1500 VA UPS – Rackmount Stackable to:
1500 VA UPS | 3000 VA UPS | 4500 VA UPS | 6000 VA UPS
1U 1200 watts UPS – Rackmount Stackable to:
1200 watts UPS | 2400 watts UPS | 3600 watts UPS | 4800 watts UPS
2U 3000 VA UPS – Rackmount Stackable to:
3000 VA UPS | 6000 VA UPS | 9000 VA UPS
2U 2400 watts UPS – Rackmount Stackable to:
2400 watts UPS | 4800 watts UPS | 7200 watts UPS
AC Input Voltage: 100 – 264 VAC, 47 – 400 Hz.
DC Output Voltage: 48 VDC.
Amperage: 10.4 Ah.
Battery Backup: 24+ Minutes at 25C, 80% Load.
