TELECOM-SEALED SeriesTM 12V AC DC Power Supply

Weatherproof 12V AC DC Power Supply provides reliable, cost
effective environmentally sealed power conversion.

IEEE Standards
Protection | Energy & Standby | System Reliability |
Operations & Safety | Maintenance

UL Standards
Health & Safety | Cybersecurity | Rain Nozzles |
Temperature Control | Environment

TUV & CE Standards
Safety & Quality | OSHA and SCC regulation |
Electrical & Fire Safety

* Units are designed to meet these standards but, each unit must be tested at system level. Shielded cables and line filters required. Read more

Side-Nav_Image-03

Weatherproof 12V AC DC Power Supply, Weatherproof 12V Power Supply, Weatherproof Sealed 12V Power Supply, Sealed 12V Power Supply

Our Weatherproof 12V AC DC Power Supply is an ultra-high efficiency family of environmentally Weatherproof Sealed 12V Power Supply

The TELECOM-SEALED SeriesTM includes Weatherproof 12V AC DC Power Supply that provides High Reliability with affordable off the shelf availability in a product that performs under extreme conditions, even submerged under water!

Our Weatherproof 12V AC DC Power Supply provides reliable, cost effective environmentally sealed power conversion. The TELECOM-SEALED SeriesTM offers a highly reliable standard Weatherproof off the shelf solution with short lead times in a rugged design. The TELECOM-SEALED SeriesTM from AJPS operates from wide range AC input (85 – 305VAC) and is available in standard output voltages of 12, 24 and 48 VDC. Each product is Hermetically Sealed and carries an IP67 rating for ingress of dirt/dust and water. The products are cooled via natural conduction/convection (no air flow needed) supported by ultra High Efficiency up to 94%. Units can be operated in series for higher power applications.

Highlights

  • Sealed enclosure, IP67 ingress protection
  • High Efficiency (up to 94%)
  • Universal input voltage range (85 – 305VAC)
  • DC input also available
  • Input surge current limiting
  • 400 Watt Max Power (parallelable for higher power)
  • 12, 24 and 48 VDC standard output voltages
  • Low stand-by power consumption (<0.5 W)
  • Low earth / touch leakage current
  • Active PFC, EN61000-3-2 compliant (Class C, >25% load)
  • OV, OC and SC protections
  • Stand-by +5Vdc 2A and Auxiliary +12Vdc 1A outputs
  • Remote On / Off signal
  • Over temperature protections
