The AERO-Trans SeriesTM provides AC Voltage conversion from 50 to 5000VA.
These systems have internal surge suppression and wide temperature ranges.
MIL-STD-810F
Humidity | Altitude | Sand and Dust |
Shock and Vibration | Temperature
MIL-STD-461E
RE101 | RE102 | CE101 | CE102 | CE103
MIL-STD-882D
MIL-STD-1472F
MIL-STD-1474D
* Units are designed to meet these standards but, each unit must be tested at system level. Shielded cables and line filters required. Read more
Aerospace Ruggedized COTS Power Transformer. Mil Aero Rugged Power Transformer
AJ’s Power Source Inc. is pleased to announce the release of our new Aerospace Power Transformer Systems. AERO-Trans SeriesTM is a Ruggedized COTS Aerospace Compliant Transformer System Built for deployment and operations equipment. This unit is available to all the Aerospace Industry, homeland security and government contractors. Light weight auto transformer built for reliability, this fully Ruggedized system is ready for world wide deployment.
The AERO-Trans SeriesTM provides AC Voltage conversion from 50 to 5000VA. These systems have internal surge suppression and wide temperature ranges. This unit is built with 120 thousandths aluminum walls and mounts. The system has a high end, built in breaker that is externally resettable.
Aerospace Rugged Tactical Power Transformer Built for Harsh Environments Ready for World Wide Deployment.
Our Rugged Tactical Power Transformer has been designed for Ruggedized for Field Use, -40 to 70C operation, light weight auto transformer, environmentally sealed, external resettable breaker, solid and stackable, up to 5000VA and custom configurations are available.
We can customize your ruggedized COTS power transformer to suit your needs. Call our office today! (813) 996-2583
AJPS’s has been supplying high end Aerospace Transformers Power solutions to the NASA, Airborne, UAV, Imaging, Satellite and Helicopter for over 20 years. All of AJPS’s operations are monitored and controlled by an ISO 9001:2000 based quality systems. To learn more about our custom capabilities please, Contact us online or call our main office at (813) 996-2583 our experienced Representatives will provide you a custom Quote for your custom power requirements.
Highlights
• -40 to 70C Operation
• Light Weight Auto Transformer
• Environmentally Sealed
• External Resettable Breaker
• Solid and Stackable
• Up to 5000VA
• Custom Configurations Available
• Ruggedized for Field Use
- Part Number: MIL-Trans-50A
- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 50VA
- Chassis Size: A
Part Number: MIL-Trans-100A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 100VA
- Chassis Size: A
Part Number: MIL-Trans-250A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 250VA
- Chassis Size: B
Part Number: MIL-Trans-500A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 500VA
- Chassis Size: C
Part Number: MIL-Trans-1000A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 1000VA
- Chassis Size: D
Part Number: MIL-Trans-1500A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 1500VA
- Chassis Size: E
Part Number: MIL-Trans-2000A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 2000VA
- Chassis Size: F
Part Number: MIL-Trans-3000A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 3000VA
- Chassis Size: G
Part Number: MIL-Trans-5000A- Input Voltage: 230VAC
- Output Voltage: 120VAC
- Power Output: 5000VA
- Chassis Size: H
Part Number: MIL-Trans-50B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 50VA
- Chassis Size: A
Part Number: MIL-Trans-100B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 100VA
- Chassis Size: A
Part Number: MIL-Trans-250B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 250VA
- Chassis Size: B
Part Number: MIL-Trans-500B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 500VA
- Chassis Size: C
Part Number: MIL-Trans-1000B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 1000VA
- Chassis Size: D
Part Number: MIL-Trans-1500B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 1500VA
- Chassis Size: E
Part Number: MIL-Trans-2000B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 2000VA
- Chassis Size: F
Part Number: MIL-Trans-3000B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 3000VA
- Chassis Size: G
Part Number: MIL-Trans-5000B- Input Voltage: 120VAC
- Output Voltage: 230VAC
- Power Output: 5000VA
- Chassis Size: H
-
