Industrial Waterproof IP65 AC DC Power Supply

The Industrial Sealed Heatsink AC DC Power Supply series is an
ultra-high efficiency family of Industrial Sealed IP67 Power Supplies.

IEEE Standards
Protection | Energy & Standby | System Reliability |
Operations & Safety | Maintenance

UL Standards
Health & Safety | Cybersecurity | Rain Nozzles |
Temperature Control | Environment

TUV & CE Standards
Safety & Quality | OSHA and SCC regulation |
Electrical & Fire Safety

* Units are designed to meet these standards but, each unit must be tested at system level. Shielded cables and line filters required. Read more

Side-Nav_Image-03

Industrial Waterproof IP65 AC DC Power Supply, Industrial IP65 Power Supplies, Custom Industrial Waterproof Power Supply, Industrial Waterproof Power Supply

Our Industrial Waterproof IP65 AC DC Power Supply is an environmentally sealed, ultra-high efficiency family of Industrial Power Supplies that will operate reliably to 70C

The INDUSTRIAL-SEALED SeriesTM includes Industrial Waterproof IP65 AC DC Power Supply that provide High Reliability with off the shelf availability and affordability in a product that performs under extreme conditions, even submerged under water or exposed to 70C operating temperatures!

Our Industrial Waterproof IP65 AC DC Power Supply provides reliable, cost effective power conversion. The INDUSTRIAL-SEALED SeriesTM offers a highly reliable standard industrial off the shelf solution while providing short lead times in a rugged design. The INDUSTRIAL-SEALED SeriesTM from AJPS operates from wide range AC input (85 – 305VAC) as well as DC and is available in standard output voltages of 12, 24 and 48 VDC. Each product is Hermetically Sealed and carries an IP65 rating for ingress of dirt/dust and water. The products are cooled via natural conduction/convection (no air flow needed) and supported by ultra High Efficiency up to 94%. Units can be operated in series for higher power applications.

Highlights

  • Sealed enclosure, IP65 ingress protection
  • High Efficiency (up to 94%)
  • Universal input voltage range (85 – 305VAC)
  • DC input also available
  • Input surge current limiting
  • 400 Watt Max Power (parallelable for higher power)
  • 12, 24 and 48 VDC standard output voltages
  • Low stand-by power consumption (<0.5 W)
  • Low earth / touch leakage current
  • Active PFC, EN61000-3-2 compliant (Class C, >25% load)
  • OV, OC and SC protections
  • Stand-by +5Vdc 2A and Auxiliary +12Vdc 1A outputs
  • Remote On / Off signal
  • Over temperature protections
Industrial Waterproof IP65 AC DC Power Supply, Industrial IP65 Power Supplies, Custom Industrial Waterproof Power Supply, Industrial Waterproof Power Supply
